4-11-4 Set the Page color

Page color is the default print color for multi-pages. You can specify the print color for multi-pages efficiently by setting the page color. You can set the same item to a different print color for each page.

Use the following procedure to set the page color for each item.

To work with items while verifying their colors on the Form Editor, configure the settings in advance to display the page in print colors. For details, see "4-11-1 Design colors and print colors".

  1. Click the Page color settings button from the Properties Editor of the paper to display the Page color settings dialog.

  2. Specify the colors by clicking the cell of the corresponding item name and page column.

    If you specify a color for each page column, specify the color in the cell at the bottom of the Page color settings dialog, and then select one of the cells of the item name in the page column, and click the Set color to selected column button.


    Select any item name cells in the page column and click the "Set color to selected column" button

  3. Click the OK button.

    The page color is set.
